ISO3082DWR
TRANSCEIVER ISOLATED CAN 16SOIC
Texas Instruments
View in 3D
Want something different?
Bypass caps, pull-ups, strapping resistors, custom silkscreen & more
Design a Custom BoardAbout This Component
Half-duplex CAN bus transceiver with integrated galvanic isolation providing 2.5kV minimum isolation between logic and bus sides. Supports standard CAN protocols up to 1Mbps with fail-safe input structure. Ideal for industrial control, automotive networks, and systems requiring noise immunity in electrically harsh environments.
Package: SOIC-16W (7.5mm wide) · 16 pins
Why does this need a breakout?
SOIC-16W uses 1.27mm pitch and surface-mount construction, making it difficult to hand-solder and incompatible with breadboards. A breakout board converts the 16 pins to through-hole connectors, enabling direct breadboarding and eliminating soldering risk during prototyping of real-time clocks, transceivers, flash memory, and gate-drive optocouplers.
Specifications
ELECTRICAL CHARACTERISTICS
| Manufacturer | Texas Instruments |
| Part Number | ISO3082DWR |
| Package | SOIC-16W (7.5mm wide) |
| Pin Count | 16 |
| Data Rate | 200kbps |
| Duplex | Half |
| Number of Drivers/Receivers | 2/2 |
| Protocol | RS422, RS485 |
| Type | Transceiver, Isolated |
| Voltage - Supply | 3.15V ~ 5.5V, 4.5V ~ 5.5V |
What's Included
BILL OF MATERIALS
- 1x ISO3082DWR soldered onto breakout PCB
- Pin headers pre-soldered (2.54mm / 0.1" pitch)
- All IC pins broken out to 2.54mm headers
Breakout Board Design
PCB SPECIFICATIONS
WIDTH
< 0.9" (straddles breadboard)
PITCH
2.54mm standard
SOLDER
Lead-free, reflow assembled
FINISH
FR4, lead-free HASL
